| UNIT : IN (MM) |
SIZE
DIAMETER×THICKNESS×HOLE |
WHITE
ALUMINUM OXIDE |
GREEN SIC
SPEC. |
6×1/4-1×11/4 |
(150×6.4-25.4×31.75) |
|
* GRAIN SIZE : 46-240
* HARDNESS
: H,I,K,L
* STRUCTURE
: 5-13 |
* GRAIN SIZE
: 46-180
* HARDNESS
: G,H,I,J,K,L
|
7×1/4-1×11/4 |
(180×6.4-25.4×31.75) |
|
* 7×3/4,1-1×11/4 |
(180×19.05,25.4×31.75) |
|
8×1/2-1×11/4 |
(205×12.7-25.4×31.75) |
|
10×1/2-1×2,3 |
(255×12.7-25.4×8,76.2) |
|
12×3/4-2×3.5 |
(305×19.05-50.8×76.2,127) |
|
* 12×11/2-3.5 |
(305×38.1-76.2,127) |
|
* 12×2×3,5 |
(305×50.8×76.2.127) |
|
14×1-2×5.8 |
(355×25.4-50.8×127,203.2) |
|
16×1-2×5.8 |
(405×25.4-50.8×127,203.2) |
|
20×11/2-2×5.8 |
(510×38.1-50.8×127,203.2) |
|
* One side recessed.
** Two side recessed. |
