| UNIT : IN (MM) |
SIZE
DIAMETER×THICKNESS×HOLE |
MAX. SPEED |
APPLICATION |
SINGLE |
DOUBLE |
1½×1/16, 1/8×H3 1/2
(38×1.6, 3.2×H+)
|
36,000 |
40,200 |
| A24Q |
: Fast cutting for
metal.
|
| A46s |
: Long life for pipe,
cast steel &
graphite iron.
|
| WA36R |
: Mild steel,
Stainless steel.
|
| 19A36R |
: Stainless steel.
|
| A46P |
: Non-ferrous metal
(Brass, Bronze,
Copper etc)
|
| C24R |
: Fast cutting for
stone.
|
| C30R |
: General purpose
for stone.
|
| C36S |
: Artificial & natural
stone, concrete
etc. |
|
2×1/16, 1/8×H+
(50×1.6, 3.2×H+) |
27,400 |
30,500 |
3×1/16, 1/8, 3/16×H+
(75×1.6-3.2, 4.8×H+) |
18,300 |
20,100 |
4×1/16, 1/8, 3/16×H+
(100×1.6-3.2, 4.8×H+) |
13,700 |
15,200 |
4½×1/16, 1/8, 3/16×H+
(115×1.6, 3.2, 4.8×H+) |
11,900 |
13,300 |
5×1/16, 1/8, 3/16×H+
(125×1.6, 3.2, 4.8×H+) |
11,000 |
12,200 |
6×1/16, 1/8, 3/16×H+
(150×1.6, 3.2, 4.8×H+) |
9,100 |
10,000 |
7×3/32, 1/8×H+
(180×2.4, 3.2×H+) |
7,600 |
8,500 |
8×3/32, 1/8×H+
(205×2.4, 3.2×H+) |
6,700 |
7,500 |
9×3/32, 1/8×H+
(230×2.4, 3.2×H+) |
5,900 |
6,600 |
10×3/32, 1/8×H+
(255×2.4, 3.2×H+) |
5,400 |
6,100 |
12×3/32, 1/8, 5/32×H+
(305×2.4, 3.2, 4×H+) |
4,500 |
5,100 |
14×3/32, 1/8×H+
(355×2.4×3.2, 4×H+) |
3,800 |
4,400 |
6×1/8, 5/32, 3/16×H+
(405×3.2, 4, 4.8×H+) |
3,400 |
3,800 |
18×1/8, 5/32, 3/16×H+
(455×3.2, 4, 4.8×H+) |
3,000 |
3,400 |
20×1/8, 5/32, 3/16×H+
(510×3.2, 4, 4.8×H+) |
2,700 |
3,100 |
24×3/16, 1/4×H+
(610×4.8, 6.4×H+) |
2,250 |
2,500 |
| * H+ : |
Hole size is changable by Customer's Requirements. |
|
|
|
| |
 |
|
UNIT : IN (MM) |
SIZE
DIAMETER×THICKNESS×HOLE |
GRAIN SIZE |
APPLICATION |
4×1/16, 1/8×1/2
(100×1.6, 3.2×12.7)
|
|
|
For high speed machine & quick cutting for metal. |
|
6×1/16, 1/8×1/2, 5/8
(80×1.6, 3.2×12.7, 15.88) |
|
7×1/16, 1/8×1, 11/4
(180×1.6, 3.2×25.4, 31.75) |
|
8×1/16, 1/8×5/8, 11/4
(205×1.6, 3.2×12.7, 31.75) |
|
10×3/32, 1/8, 5/8, 11/4
(255×2.4, 3.2×12.7, 31.75) |
|
12×3/32×3/5, 11/4
(305×2.4, 3.2×19.05, 31.75) |
|
|
|
| |
|
|
|
